Steering Assembly 20mm Complete Brand New w/Black Countersunk Washers

Steering Assembly 20mm Complete Brand New w/Black Countersunk Washers

ABSOLUTELY BRAND NEW complete steering assembly! Bolt-on and GO!

NEW MODEL - Includes Steering Column STOP Collar (Anodised Black) and bolt kit to fit column to chassis!



COMPLETE FROM BOSS TO NUT

Everything you need is in the kit - all the nuts, bolts, washers, and bush! Just add your steering wheel (or add one from our store)



WIDE RANGE OF COLOURS

Our kits are in stock and available with coloured countersunk washers in Gold, Blue, Red, Black, Purple or Silver!  This listing is for the colour pictured.



RACE KART BOSS

Our included bosses offer standardised PCD's to suit almost all race kart steering wheels.  You'll be sure your current wheel will bolt up!  (Holes centres are set 41mm from each other)
Comes with everything you need to connect it up and use. PLUS FREE countersunk washers, bolts and nuts.  (See main pictures title for colour of washers)



1x Steering BOSS (standard race kart steering wheel boss -

1x Anodised Steering Column Stop Collar
3x Boss Countersunk Washers Anodised (Colour as per Title)
3x Boss Countersunk High Tensile Bolts & Nyloc Nuts
1x Steering SHAFT
4x TIE ROD ENDS
2x TIE RODS
5x Tie Rod Countersunk Washers Anodised (Colour as per Title)
4x Tie Rod Countersunk High Tensile Bolts & Nyloc Nuts

1x Nylon Steering Bush (NOT PICTURED, BUT SUPPLIED)

1x Steering Bush High Tensile Bolt , Nyloc & Washer

Shaft Dimensions:
Dimension A: 500mm

Dimension D - Bottom of shaft (Bottom of A) to bottom bracket Tie Rod Holder (where B&C Meet) = 75mm

Dimension Unassigned - Bottom of shaft (Bottom of A) to top bracket = 105mm

Click the picture below to view the tie rod measuring guide to assist in determining the correct size for your kart.

Not sure what length you need?  Click here to view our guide and sizing grid.

NOT SURE HOW TO BUY THIS ITEM?  Click here to read our simple walk-through guide.

SteeringGuide

Details
SKU SRAC2K
Base product price: $169.00
including GST 10%
: *
: *
: *
