Go Kart Parts List

Go Kart Parts List

Are you considering building your own race go-kart?  Building a kart is great fun and an excellent learning tool to understanding motorised machinery.  We have put together a general list of parts required to build a basic kart for you to take the hassle out of figuring out everything to buy.

The parts list below includes all the parts required to complete a full kart, including every single nut and bolt supplied in our ready-to-build kit.  You can click any underlined item to view that part in our store.

The codes to the right of the items can be used to locate the individual components in our store.  For example, if you search our store using the magnifying glass search box at the top right you'll be able to find the code before the colon - we've highlighted the code below for reference:

Plastic Plastics Side Pods set (New Style) (PSPC1:E12): 1 item(s)

Here is the complete list of parts in our complete DIY kart kit:

CPR RS-32 Senior Chassis and Componentry



Fit Kit - CPR Stub Axle Set SILVER

  • Front Wheel Nut suit 16mm thread (WNFBK4:H22N): 2 item(s)

  • Go Kart Square Hex Socket Head Bolt M8 90mm long High Tensile NEW with Nyloc & Washer (BSM890S:H22M): 2 item(s)

  • Wheel Spacer Washer 10mm Anodised Silver (WSWC2S:I22P): 6 item(s)

  • Wheel Spacer Washer 5mm Anodised Silver (WSWC1S:I22P): 4 item(s)

  • Sleeve Reducer 12mm OD 8mmID Suit Stub Axle Brackets and Frames PK4 (SPCS128:I32R): 1 item(s)

  • Stub Axle Spindle Kingpin Spacer Washer 3.3mm Thick 8mmID (SSWC01:I32R): 8 item(s)


Fit Kit - Hydraulic Brake Set
  • Zip Tie Cable Tie suit brake line (BZT001:I33): 3 item(s)

  • Go Kart Square Hex Socket Head Bolt M8 20mm long High Tensile NEW with Nyloc & Washer (BSM820S:H22M): 2 item(s)

  • Go Kart Square Hex Socket Head Bolt M8 60mm long High Tensile NEW with Nyloc & Washer (BSM860S:H22M): 2 item(s)

  • Brake Rod Retainer Pin & Split Pin suit CPR Brake Rod (PNBRRK:I43P): 2 item(s)


Complete Wheels Front & Rear Alloy Rims and Tyres SET (4pcs) Brand New
  • Complete Wheels Front Alloy Rims and Tyres Pair Brand New (Special) (WPFRD_PF:): 1 item(s)


Sprocket Split Aluminium 35 Pitch 59 Teeth
Complete Plastic Plastics Sidepods Nosecone and Nassau Panel set (Includes Sidepod Bars)
  • Plastic Plastics Nosecone (New Style) BASE PRODUCT (PSNC1_BASE:E12): 1 item(s)

  • Plastic Plastics Side Pods set (New Style) (PSPC1:E12): 1 item(s)

  • Plastic Plastics Nassau Panel (New Style) (PSNAC1:E12): 1 item(s)

  • Go Kart Square Hex Socket Head Bolt M8 20mm long High Tensile NEW with Nyloc & Washer (BSM820S:H22M): 12 item(s)

  • Sidepods Sidepod Bars Pair suit new style karts and pods (SPBC02:O13): 1 item(s)

  • Nassau Panel Retainer bracket Kit suits newer karts (CRG NA2 Style) and our PSCC1 kits (NPBCNA2:I32C): 1 item(s)


Go Kart Chain 35 Pitch 1m BRAND NEW
4-Stroke Engine LIFAN OHV 6.5hp 192cc Complete with 12T Clutch
  • 4-Stroke Engine LIFAN OHV 6.5hp 192cc Complete (ENCL65:Q2): 1 item(s)

  • Clutch Dry SR Series 35 Pitch 12 Tooth 19mm (3/4inch) bore (CLC3512:J12): 1 item(s)


Complete 40mm Axle Kit 8mm Keyway Silver
  • Shaft 40mm Axle 8mm Keyway 1040mm Medium (AXSC408:M23): 1 item(s)

  • Complete Brake Disc and 40mm Hub Carrier 8mm Keyway Silver (BDHC408S:M12): 1 item(s)

  • 40mm Bearing Carrier Only Silver (Not for Individual Sale) (BH40S:M11): 2 item(s)

  • 40mm Bearing (ABPQ40:N23): 2 item(s)

  • Go Kart Countersunk Bolt M8 50mm long High Tensile NEW with Nyloc & Washer (BCM850S:H22K): 6 item(s)

  • Go Kart Countersunk Washer 8mmID Black NEW (CSWC8K:I22E): 6 item(s)

  • Sprocket Carrier (Hub Only) suit 40mm Axle 8mm Keyway Silver (SHC408S:M11): 1 item(s)

  • Go Kart Countersunk Bolt M6 25mm long High Tensile NEW with Nyloc & Washer (BCM625S:H22K): 6 item(s)

  • Go Kart Countersunk Washer 6mmID Black NEW (CSWC6K:I22E): 6 item(s)

  • Rear Wheel Hub Hubs PAIR suit 40mm Axle 8mm Keyway Sillver (WHC408S:M13): 1 item(s)


Seat Performance Nylon Size - 3
Fit Kit - CPR Seat Set Silver
  • Go Kart Countersunk Bolt M8 45mm long High Tensile NEW with Nyloc & Washer (BCM845S:H22K): 6 item(s)

  • Seat Spacer 8mm Thick 8mmID 30mmOD Suit Seat Support Bolts, Engine Mounts PK4 (SESPC1:I22T): 2 item(s)

  • Countersunk Washer 8mmID Silver for Seats (CSWC8SS:I22P): 6 item(s)


Fit Kit - Pedal Set
  • Go Kart Zinc Plated Pedal Bolt M10 70mm long High Tensile NEW with Nyloc (BZM1070S:): 2 item(s)

  • Go Kart Square Hex Socket Head Bolt M6 35mm long High Tensile NEW with Nyloc & Washer (BSM635S:H22M): 3 item(s)

  • Pedal Return Spring (Heavy Spring Rate) (SPPRHD:I32Q): 2 item(s)


Steering Wheel Flat Top Stiched Blue (Wheel Only)
Fit Kit - CPR Steering Set Silver
  • Go Kart Square Hex Socket Head Bolt M8 30mm long High Tensile NEW with Nyloc & Washer (BSM830S:H22M): 2 item(s)

  • Go Kart Zinc Plated Hex Head Bolt M8 15mm long NEW (BZM815S:H22M): 2 item(s)

  • Go Kart Countersunk Bolt M8 50mm long High Tensile NEW with Nyloc & Washer (BCM850S:H22K): 2 item(s)

  • Go Kart Countersunk Washer 8mmID Silver NEW (CSWC8S:I22P): 2 item(s)

  • Spacer 8mm Wide 8mmID Suit Steering Shaft Support and Tie Rod Support PK4 (SPCRC88:I42N): 2 item(s)

  • Go Kart King-Pin Bolt M8 75mm long High Tensile NEW with Nyloc & Washer KINGPIN (BSM875S:H22P): 1 item(s)

  • Tie Rod Ends (8mm Male) Pair (Includes Locking Nuts) To Suit Steering (ENDMC1:I42C, I31): 2 item(s)

  • Go Kart Square Hex Socket Head Bolt M6 25mm long High Tensile NEW with Nyloc & Washer (BSM625S:H22M): 3 item(s)

  • Go Kart Square Hex Socket Head Bolt M6 40mm long High Tensile NEW with Nyloc & Washer (BSM640S:H22M): 1 item(s)


Bolt Fit Kit Engine Mount Suit Honda Clone Engines and CPR Chassis
  • Seat Spacer 8mm Thick 8mmID 30mmOD Suit Seat Support Bolts, Engine Mounts PK4 (SESPC1:I22T): 1 item(s)

  • Go Kart Zinc Plated Hex Head Bolt M8 50mm long NEW with Nyloc & Washer (BZM850S:H22M): 4 item(s)

  • Go Kart Zinc Plated Ring-End Bolt M8 50mm long NEW with Nyloc & Washer (BREM8S:I32S): 4 item(s)

  • Go Kart Zinc Plated Ring Spacer32mmID 40mmOD 8mm Thick NEW (ERSC01:I32S): 4 item(s)

  • Crankshaft Retainer Washer (suit GX200) (M8WSHROD:I42N, I31): 4 item(s)

  • Throttle Cable Seat Carby Terminator Adjuster (suit 4 stroke) (TTSC04:I32S): 1 item(s)


Fuel Tank 9L KIT (includes Fuel outlet Barb, 1.5m Fuel Line & Fuel Filter & Fitting Thumbscrew)
  • Fuel Tank 9L (BASE TANK) (FTKC01_BASE:C22): 1 item(s)

  • Fuel Tank Spigot Barb Nipple to suit FTKC01 (FTSPC1:I43P): 1 item(s)

  • Bracket and Retainer bolt suits CPR Fuel Tank FTKC01 (BRFRBK:I22W): 1 item(s)

  • Fuel Filter Go Kart GT-Race Series Suit 4-9mmID (FUFC05:I33): 1 item(s)

  • Fuel Line Go Kart Race Type Clear 5.5mmID 1m Length (FLIC01:H31): 2 item(s)


Fit Kit - CPR Floor and Bodywork Set Silver
  • Go Kart Phillips Head Bolt M6 15mm long Zinc Plated NEW with Nyloc & Washer (BPM615S:H22M): 12 item(s)

  • Clamp for Nosecone Quick Release PAIR (CLNC01:O13): 1 item(s)

  • Go Kart Countersunk Bolt M6 25mm long High Tensile NEW with Nyloc & Washer (BCM625S:H22K): 2 item(s)

  • Go Kart Countersunk Washer 6mmID Silver NEW (CSWC6S:I22P): 2 item(s)

  • Go Kart Square Hex Socket Head Bolt M6 40mm long High Tensile NEW with Nyloc & Washer (BSM640S:H22M): 2 item(s)

  • Go Kart Nylon Spacer 6mm Suit Floorpan or Side Pods 10pk (SPPC6K:I43L): 1 item(s)




 If you prefer to build one of our complete kits, you can find them here:
