Go Kart 2-Stroke Engine PRD...



We've received a scoop purchase of these super-reliable, low cost high quality engines - they're cheap because they were a clearance deal!  You get awesome power in a complete electric start package - turnkey, with everything from muffler through to starter button and battery included!  Even a clutch is included and fitted to the unit!  AMAZING VALUE.



This 18hp engine is comparable to the KT100S and can be raced against it quite evenly.



If you've got a non-electric start KT100S and want to race the guys with an electric start model, this is the perfect way to do it!  A purpose built race engine - not a suped up pump motor!



Perfect for the local track, recreation, or the backyard speedway!

Capacity 98cc

Horse Power 18HP

Restricted Horse Power N/A

Bore 49.92mm

Stroke 50.00mm

Piston Aluminium

Ring Type Dykes

Cooling System Air Cooled

Radiator N/A

Air Admission Piston Port

Reed Petals N/A

Reed Manifold N/A

Head Volume 10cc

Conrod Forged 100mm Medium

Ignition PRD #7 Magneto

Spark Plug Cap PRD Resistor

Carburettor Walbro WB42 W/Choke

Exhaust Straight Coned / Adjustable Length

Starting System Electric Start

Drive System Centrifugal Steel Clutch

Airbox Silver 23mm

Air Filter Internal Filter

Battery Yuasa

Cylinder Liner Cast Iron

Ports Cast

Power Valve N/A

Rebuild Time Top End approx 15hrs

Rebuild Time Bottom End approx 30hrs

Max RPM 14500-15000 (recommended)







Included in the kit Engine



10T 219p Clutch



Carburettor



Carburettor Spacer Block



Carburettor Spacer Gaskets



Airbox



Airbox Adaptor



Air Filter Red Short



Airbox Clamp



Spark Plug



Exhaust Gasket



Exhaust Header



Exhaust Flex Spacer



Exhaust Flex Sealer



Exhaust Springs



Exhaust Muffler



Wire Loom



Starter Button



Off Button



Switch Bracket



Battery Bracket



Battery



RECOMMEND FUEL:OIL RATIO 16:1



RECOMMEND CARB BASE TUNE 1+1/2 LOW & 1/4 HIGH
