Go Kart Engine Mount Billet...

***NOTE:  Picture #1 is of EMTA01 but is used for dimensional representation.  This item is pictured correctly in all other pictures***

Fully Adjustable Anodised Billet engine mounting system.  (lateral position adjustment)

15 degree angled.

Suits 90 or 92mm rail centre to centre and 28-32mm tubes.

The perfect mount for switching to 4-stroke engines (threaded holes designed for Honda GX200/160 and clone engines as well as Briggs/Vangard ~200cc 6-6.5hp engines including World Formula, Animal etc.

Complete top, middle and bottom brackets with all required bolts.

Dimensions:

A (Side edge to outer hole centre) - ~25mm

B (outer hole centre to centre hole centre) - ~25mm

C (centre hole centre to inner hole centre) - ~25mm

D (Side edge to inner hole centre) - ~25mm

E (Side edge to edge of slot) - ~ 24mm

F (Slot length) - ~61mm

*Note both top and bottom plates are symettrical

G (Slot edge to centre of inner engine rail) ~10mm

GX200 base is 162mm x 78mm hole centre to hole centre.
